Product Details
Place of Origin: China
Brand Name: TUNSING
Certification: ISO 9001 SGS Oeke-TEX
Model Number: DS220
Payment & Shipping Terms
Minimum Order Quantity: 20kg
Price: negotiable
Packaging Details: 20kilogram/bag
Delivery Time: 3-5 work days after received the payment
Payment Terms: L/C, T/T, Western Union, Western Union
Supply Ability: 6000000 kg/Month
NAME: |
Hot Melt Adhesive Powder |
Melt Point DSC: |
95-115 ℃ |
Melt Index ASTM D-1238: |
30±7 G/10min |
Hardness: |
80±3 Shore A |
Powder Size Range: |
80-200 μm |
Composition: |
TPU |
Temperature: |
110-130℃ |
Density ASTM D-792: |
1.20±0.02 G/cm³ |
NAME: |
Hot Melt Adhesive Powder |
Melt Point DSC: |
95-115 ℃ |
Melt Index ASTM D-1238: |
30±7 G/10min |
Hardness: |
80±3 Shore A |
Powder Size Range: |
80-200 μm |
Composition: |
TPU |
Temperature: |
110-130℃ |
Density ASTM D-792: |
1.20±0.02 G/cm³ |
High Elastic 80-200um Hot Melt Powder DTF Adhesive Powder for Heat Transfer Printing
Hot Melt Adhesive Powder
DTF Powder
The TPU hot melt adhesive powder offers a soft and flexible texture when applied. This characteristic makes it suitable for applications where a soft touch or a comfortable feel is desired.TPU hot melt adhesive powder exhibits good resilience, meaning it can recover its original shape after being stretched or deformed. This property allows it to withstand mechanical stresses and maintain its bonding integrity.The TPU hot melt adhesive powder possesses excellent stretchability, making it suitable for applications that require flexibility and elongation. TPU hot melt adhesive powder can bond materials that undergo stretching or movement without compromising the adhesive bond.
The Physical Characteristics of Hot Melt Adhesive Powder
Physical Characteristics:
| Property | Criterion |
| Appearance | White powder |
| Composition | TPU |
| Density ASTM D-792 | 1.20±0.02 g/cm³ |
| Melt Point DSC | 95-115 ℃ |
| Melt Index ASTM D-1238 | 30±7 g/10min |
| Hardness | 80±3 Shore A |
| Powder size range | 0-80 μm |
| 80-200 μm | |
| 150-250 μm | |
| Resistance to yellowing (level) | 2.0-3.0 |
Technical Parameters:
|
Bonding Parameters ( reference only) |
Temperature | 110-130℃ |
| Press | 1.5-2.5 kg/cm2 | |
| Time | 8-15 S | |
| Washing Resistance | 40℃ | Excellent |
| 60℃ | General | |
| 90℃ | / |
Packaging and Storage Conditions:
| Packaging | 20KG inner PE bag+ kraft paper bag |
| Storage Conditions | Store in cool,ventilated,dark,dry room temperature. |
The Composition of TPU Hot Melt Adhesive Powder
Thermoplastic polyurethane (TPU) hot melt adhesive powder is composed of several key components. Here is a description of the typical composition of TPU hot melt adhesive powder:
1.Polyurethane Resin: The primary component of TPU hot melt adhesive powder is the polyurethane resin. TPU Hot Melt Adhesive Powder is a thermoplastic polymer that provides the adhesive with its main adhesive properties, such as bonding strength, flexibility, and heat resistance.
2.Plasticizers: Plasticizers are often added to TPU hot melt adhesive powder to enhance its flexibility and softness. These additives help improve the adhesive's ability to conform to different substrates and provide a desirable tactile feel.
3.Tackifiers: Tackifiers are incorporated into the TPU hot melt adhesive powder to enhance its initial tack or stickiness. These additives improve the adhesive's ability to quickly bond to surfaces upon application, ensuring efficient and reliable adhesion.
4.Stabilizers: Stabilizers are included in the formulation of TPU hot melt adhesive powder to improve its resistance to heat, oxidation, and UV degradation. These additives help maintain the adhesive's performance and stability over time, ensuring its longevity and durability.
5.Other Additives: Depending on the specific application requirements, TPU hot melt adhesive powder may contain additional additives such as fillers, pigments, or crosslinking agents. These additives can provide specific functionalities or improve certain properties of the adhesive, such as color, strength, or chemical resistance.
The Application of TPU Hot Melt Adhesive Powder
1.Textile Industry: TPU hot melt adhesive powder is widely used in the textile industry for fabric lamination, bonding seams, attaching trims and labels, and reinforcing fabrics.
2.Footwear Industry: TPU hot melt adhesive powder is employed in footwear manufacturing for bonding shoe components, including outsoles, insoles, toe caps, and decorative elements.
3.Automotive Industry: TPU hot melt adhesive powder finds application in the automotive industry for interior components, such as bonding fabrics, foams, and trims to car seats, headliners, door panels, and carpets.
PA Hot Melt Adhesive Powder's Customer Feedback
Packing & Shipping :
packing: 20KG PER BAG
shipping: 5-7days
