Product Details
Place of Origin: China
Brand Name: Tunsing
Certification: Rohs, REACH
Model Number: DS8614
Payment & Shipping Terms
Minimum Order Quantity: 2 rolls
Price: 3.66-9.99$/Yard
Packaging Details: 1-2 rolls in one carton, each with PP bag
Delivery Time: 3-5 days
Payment Terms: T/T,Paypal
Supply Ability: 3000000 yards per month
|
Release Protection:
|
Glassine Release Paper
|
Thickness Range:
|
0.025mm - 0.30mm
|
Width Range:
|
5mm - 1580mm
|
Melting Range:
|
115-135℃
|
Melt Flow Index:
|
8±3g/10min
|
Hardness:
|
52±2 (Shore A)
|
Temperature:
|
145℃-165℃
|
Pressure:
|
0.3-0.5 Mpa
|
Time:
|
5-15 S
|
|
Release Protection:
|
Glassine Release Paper
|
|
Thickness Range:
|
0.025mm - 0.30mm
|
|
Width Range:
|
5mm - 1580mm
|
|
Melting Range:
|
115-135℃
|
|
Melt Flow Index:
|
8±3g/10min
|
|
Hardness:
|
52±2 (Shore A)
|
|
Temperature:
|
145℃-165℃
|
|
Pressure:
|
0.3-0.5 Mpa
|
|
Time:
|
5-15 S
|
DS8614 is a thermoplastic hot-melt adhesive film supported by release paper that can be repeatedly heated and plasticized. It exhibits excellent adhesion to various materials including textiles, TPU (thermoplastic polyurethane), and PVC (polyvinyl chloride). This adhesive film offers superior tactile experience with good feel and resilience, making it ideal for applications where comfort and flexibility are crucial. It also features excellent cold resistance, ensuring reliable performance even in low-temperature environments.
| Property | Specification |
|---|---|
| Colour | Foggy translucent |
| Release Protection | Glassine Release Paper |
| Thickness Range | 0.025mm - 0.30mm |
| Width Range | 5mm - 1580mm |
| Proportion | 1.18±0.02g/cm³ |
| Melt Flow Index | 12±5g/10min (ASTM D1238-04) |
| Hardness | 85±3 (Shore A) |
| Melting Range | 35-60℃ (ISO11357) |
| TG Temperature | -35±8℃ (GB/T 19466.2-2004) |
| Activation Temperature | 110-145℃ (Tunsing) |
| First Lamination | Second Implanting |
|---|---|
| Mechanical Mold Temperature: 130℃-150℃ | Mechanical Mold Temperature: 130℃-170℃ |
| Time: 5-15 seconds | Time: 8-25 seconds |
| Pressure: 0.3-0.6mpa | Pressure: 0.3-0.6mpa |
Shenzhen Tunsing Plastic Products Co., Ltd. was established in 2007 and is located in Shenzhen City, China, covering an area of 10,000 square meters. The company has a professional polymer technology team led by Master and PhD engineers, specializing in R&D, production and sales of various modified hot melt adhesives, hot melt adhesive granules, hot melt adhesive film, hot melt adhesive powder, functional film coating, ultra-fine cryogenic powder grinding and die-cutting products.
The company has passed ISO9001:2015 quality management system, ISO 14001:2015 environmental management system and ISO 45001 occupational health and safety management system certification. All products comply with environmental protection standards such as RoHS, REACH, Oeko-tex and other environmental standards.
Products are used in 3C electronics, 5G, new energy, medical care, sporting goods, luggage, clothing, and footwear. The company maintains multi-functional laboratories for material analysis, thermal analysis, mechanical performance, and environmental experiments.
Tunsing is a professional hot melt adhesive manufacturer dedicated to being your reliable bonding provider.
