Product Details
Place of Origin: shenzhen.China
Brand Name: TUNSING
Certification: ROHS, Reach
Model Number: DS8614
Payment & Shipping Terms
Minimum Order Quantity: 100 yards / roll
Price: $1 - $2/roll
Packaging Details: 1roll/ctn
Delivery Time: 3 days after payment
Payment Terms: T/T,Paypal
Supply Ability: 400000 rolls per month
Keywords: |
Hot Melt Adhesive Film |
Density: |
1.18±0.02g/cm³ |
Melt Flow Index: |
12±5g/10mins |
Hardness: |
84±3 Shore A |
Melting Range: |
100-125℃ |
Conventional Thickness: |
0.03mm,0.05mm,0.08mm,0.10mm |
Conventional Width: |
1380mm |
Conventional Length: |
100 Yards |
Keywords: |
Hot Melt Adhesive Film |
Density: |
1.18±0.02g/cm³ |
Melt Flow Index: |
12±5g/10mins |
Hardness: |
84±3 Shore A |
Melting Range: |
100-125℃ |
Conventional Thickness: |
0.03mm,0.05mm,0.08mm,0.10mm |
Conventional Width: |
1380mm |
Conventional Length: |
100 Yards |
Polyurethane Thermoplastic Pu Hot Melt Adhesive Film For Phone Case
Hot Melt Adhesive Film Product Description:
This product is a thermoplastic hot-melt adhesive film, which is supported by release paper and can be repeatedly heated and plasticized. This hot melt adhesive has excellent adhesion to textiles, TPU, PVC, PC, ABS, and has excellent cold resistance
Hot Melt Adhesive Film Physical Characteristics:
|
Appearance |
Foggy translucent |
|
Density |
1.18±0.02g/cm³ |
|
Melt Flow Index |
12±5g/10mins |
|
Hardness |
84±3 (Shore A) |
|
Melting Range |
100-125℃ |
|
Conventional Thickness |
0.03mm,0.05mm,0.08mm,0.10mm |
|
Conventional Width |
1380mm |
|
Conventional Length |
100 yards |
|
Finished product |
1380mm*100yards/roll |
Hot Melt Adhesive Film Recommended Bonding Conditions:
|
First Lamination |
Second Implanting |
||
|
Mechanical Mold Temperature |
130℃-150℃ |
Mechanical Mold Temperature |
130℃-170℃ |
|
Time |
5-15 seconds |
Time |
8-25 seconds |
|
Pressure |
0.3-0.6mpa |
Pressure |
0.3-0.6mpa |
Hot Melt Adhesive Film Application:
DS8614 is used in the bonding of clothing, embroidery, footwear, luggage, handbags, toys, hats, sports materials.
Hot Melt Adhesive Film Packing & Delivery
1 carton contains 1 roll.
Sample will be shipped by DHL, Fedex, UPS, TNT it will take 3-8 days.
It will be shipped after receiving the shipping cost.
It will be shipped according to the quantity and also after receiving the payment.
