PA Hot Melt Adhesive Film for PC PVC ABS

PA Hot Melt Adhesive Film for PC PVC ABS
PA Hot Melt Adhesive Film for PC PVC ABS

Large Image :  PA Hot Melt Adhesive Film for PC PVC ABS

Product Details:
Place of Origin: China
Brand Name: Tunsing
Certification: SGS , ISO9001
Model Number: DS0022
Payment & Shipping Terms:
Minimum Order Quantity: 200m
Price: negotiable
Packaging Details: 1PC/PE FILM, 100yard/roll, 2~4roll/CTN, or it's up on the customer's option
Delivery Time: 5-7days
Payment Terms: Western Union, L/C, T/T, PayPal
Supply Ability: 40000 Square meters per day
Detailed Product Description
Color: Light Yellow Melting Point(°C): 90-120℃
Melt Index(g/10min): 20±10g/10min Hot Pressing Temperature(°C): 130℃-190℃
Conventional Thickness: 0.055mm Conventional Width: 620MM
Length: 200m Activation Temperature: 110-170℃
High Light:

hot melt glue sheets

,

thermal lamination film

PA Hot Melt Adhesive Film for PC PVC ABS



Hot Melt Adhesive Film For Quick detail:
This product is a thermoplastic film modified hot melt adhesive, entrusted to the release of paper, can be repeatedly heated plasticizing bonding.

This kind of hot melt adhesive has a wide range of adhesive properties, including textile fabrics (cotton, nylon, polyester, acrylic, acrylic), thermosetting materials (epoxy resin, phenolic resin), PVC, ABS, PC, PI, PU, metal, leather, glass fiber and composite materials.Moreover,

it has broad activation temperature and moisture resistance, and is insoluble in ketone solvents.

Hot Melt Adhesive Film Applications:

DS0022 is applied in 3C electronics, 5G, automobile, precision instrument, medical treatment, luggage and sports goods.


Hot Melt Adhesive Film Physical Characteristics:

Colour Light Yellow Release Protection Glassine Release Paper
Proportion 1.2±0.02g/cm³ Conventional Thickness 0.055mm
Melting Range 90-120℃ (Tunsing DSC 214) Width 5mm-620mm
Liquidity Index 20±10g/10min (ASTM D1238-04) Conventional Width 620MM
Activation Temperature 110-170℃ (Tunsing) Conventional Width 620mm*200M /roll




Recommended Bonding Conditions:

First Lamination Second Implanting
Mechanical Mold Temperature 130℃-190℃ Mechanical Mold Temperature 130℃-190℃
Hot Pressing Time 5-15 seconds Hot Pressing Time 8-25 seconds
Pressure 0.3-0.6mpa Pressure 0.3-0.6mpa






NOTICE:
1, Bonding temperature and pressure as well as the time involved in the strength of the film to material. Bonding temperature must be close to the machine set the temperature, the pressure must be uniform, mold and pressure roller must be flat.
2, In different machinery and materials, the bonding conditions used will be different. The conditions marked here are only basic. The optimum bonding conditions should be made by creating suitable construction conditions for the particular application damage, direct or consequential, arising out of the use, misuse or inability to use the product.



Packing & Shipping:

Packing: 200m in roll, 2 rolls in case
Shipping: 5-7days by Express (DHL, FedEx, USP and so on)






Why Choose Us
1, more than 10 years experience in production.
2, well-known products: Sichuan Famous Brand.
3, Good quality control in production process: Quality Service AAA Grade Credit Enterprise
4, Excellent quality and Competitive price, OEM is available.
5, Stable supply: an extensive range of stock.
6, The whole process from material to end products is under supervision.

FAQ
Q1) . What is hot melt adhesive film?
A: It is just a film, and the basic material is release paper. But the film is solid in room temperature, when reach its melt point, it is able to bond other materials, Different materials of hot melt adhesive film have different performances and different usages, we need understand your products needs, then recommend you right products,
Q2).Do you accept OEM or ODM?
Yes ,we accept OEM and ODM, we are professional heat transfer material manufacturer ,having more than 10years domestic sale experience, we are able to assist you R&D new products. So if you need bonding some special materials, please don’t hesitate to let us know,
Q3).How do you ship the products?
If you are not urgent, we usually transport by sea in large quantity, which is the cheapest shipping way. And for samples and urgent cargo, we transport it by air or by express, as it is the fastest way etc,
Q4). Do you provide free sample? And how many days it will take?
Yes, of course.we provide free 3-5Y sample for your testing only need you to pay the shipping cost. We will make the sample within 3 working days and it will take 3-7days on the transportation., then you will have more confidence in our product quality and service,
Q5). How long is the lead time?
Sample lead time: 1-3 days
Bulk lead time: 7-20days(depends on order quantity),
Q6). How do I pay for my order?
We usually accept L/C ,T/T ,Western Union , Paypal.
