High Elastic Hot Melt Adhesive Glue Film Tpu Polyurethane Thermoplastic Release paper

Product Details

Place of Origin: China

Brand Name: Tunsing

Certification: ISO9001:2015 Oeko-tex RoHS REACH

Model Number: DS8613

Payment & Shipping Terms

Minimum Order Quantity: 100Y

Price: 0.6USD-2.6USD/Y

Packaging Details: 100Y/roll 2rolls/ctn

Delivery Time: 400000Y/month

Payment Terms: T/T,

Get Best Price
Highlight:

hot melt glue film

,

polyester adhesive film

Color::
White Fog Translucent
Release Liner::
Release Paper
Thickness::
0.0125mm-0.15mm
Conventional Thickness::
0.03mm,0.05mm,0.08mm
Conventional Length::
100 Yards/roll
Melting Range::
110-130℃
Activation Temperature::
110-157℃
Material::
TPU
Packing::
100 Yard/ Roll, 1rolls/ctn
Color::
White Fog Translucent
Release Liner::
Release Paper
Thickness::
0.0125mm-0.15mm
Conventional Thickness::
0.03mm,0.05mm,0.08mm
Conventional Length::
100 Yards/roll
Melting Range::
110-130℃
Activation Temperature::
110-157℃
Material::
TPU
Packing::
100 Yard/ Roll, 1rolls/ctn
High Elastic Hot Melt Adhesive Glue Film Tpu Polyurethane Thermoplastic Release paper

Tpu Polyurethane Thermoplastic High Elastic Hot Melt Adhesive Glue Film

Product: DS8613

Description:

This product is a thermoplastic hot-melt adhesive film, which is supported by release paper and can be repeatedly heated and plasticized. This hot melt adhesive has excellent adhesion to textiles, TPU, PVC, PC, ABS, and has low use temperature, easy processing and excellent cold resistance.

High Elastic Hot Melt Adhesive Glue Film Tpu Polyurethane Thermoplastic Release paper 0

Application:

DS8613 is used in the bonding of clothing, embroidery, footwear, luggage, handbags, toys, hats, sports materials.

High Elastic Hot Melt Adhesive Glue Film Tpu Polyurethane Thermoplastic Release paper 1



Composition:

Polyurethane

Physical Characteristics:

Colour White fog translucent Release Protection Glassine Release Paper
Proportion 1.20±0.02g/cm³ Thickness 0.0125mm-0.15mm
Opening time 8min Width 5mm-1480mm
Liquidity Index 10±5g/10mins (ASTM D1238-04) Conventional Thickness 0.03mm,0.05mm,0.08mm,
Hardness 97±2 (Shore A) Conventional Width 1380mm
Melting Range 110-130℃ (Tunsing DSC 214) Conventional Length 100 yards
Activation temperature 110-157℃ (Tunsing) Trimmed Size 1380mm*100yards/roll

























Recommended Bonding Conditions:

First Lamination Second Implanting
Mechanical Mold Temperature 120℃-150℃ Mechanical Mold Temperature 130℃-180℃
Hot Pressing Time 5-15 seconds Hot Pressing Time 8-25 seconds
Pressure 0.3-0.6mpa Pressure 0.3-0.6mpa


1.Bonding temperature and pressure and time relate to the bonding strength of the film to the material. The bonding temperature must be close to the temperature set by the machine, the pressure must be uniform, and the mold and press rolls must be flat.

2.The bonding conditions used will vary between machines and materials. The conditions indicated here are only basic. The most ideal bonding conditions should be established by manufacturing for the specific application.

Related products:

High Elastic Hot Melt Adhesive Glue Film Tpu Polyurethane Thermoplastic Release paper 2







Packing&shiping:



High Elastic Hot Melt Adhesive Glue Film Tpu Polyurethane Thermoplastic Release paper 3



High Elastic Hot Melt Adhesive Glue Film Tpu Polyurethane Thermoplastic Release paper 4

Enterprise spirit: innovative, efficient and dedicated
Corporate vision: corporate role model based on business principles and corporate ethics
Corporate values: respect, integrity, integrity

 Exihibition







_10

FAQ:

1 .How about hot melt adhesive film?
A: It is just a film, and the basic material is release paper. But the film is solid in room temperature, when reach its melt point, it is able to bond other materials, Different materials of hot melt adhesive film have different performances and different usages, we need understand your demands ,then recommend you right products to you.

2.

Do you accept OEM or ODM?
Yes ,we accept OEM and ODM, we are professional heat transfer material manufacturer ,having more than 10years experience. able to assist you R&D new products. So if you need bonding some special materials, please don't hesitate to let us know.

3.How do you transport the products?
If you are not urgent, we usually transport by ship because it is the cheapest way. But for the West Asia area,
we deliver by train because there is no sea to ship. And for samples and urgent cargo, we transport it by air as it is the fastest way .Of course if you have other better idea about transport, we will accept it.

4. May I have your samples?
If you need some sample for reference, please let us know your fully address/ship
mode with courier ,and we will arrange sample for your reference.

5. How long is the lead time?
Sample lead time:3-7 days
Bulk lead time:7-10 days(depends on order quantity)



6. How do I pay for my order?
We accept L/C ,T/T ,Western Union , Paypal , Escrow
