Product Details
Place of Origin: China
Brand Name: TUNSING
Certification: RoHs, REACH,
Model Number: DS001TS
Payment & Shipping Terms
Minimum Order Quantity: 100 yards
Price: USD 0.2-0.4per yard
Packaging Details: 2 roll in per carton
Delivery Time: shipped in 3-5days after payment
Payment Terms: T/T
Supply Ability: 3000kg per day
Keywords: |
Hot Melt Adhesive FIlm |
Release Protection: |
Glassine Release Paper |
Colour: |
Milky White Translucent |
Melt Point: |
90-120℃ |
Conventional Width: |
500mm,1000mm,1280mm,1480mm |
Conventional Length: |
100 Yards |
Keywords: |
Hot Melt Adhesive FIlm |
Release Protection: |
Glassine Release Paper |
Colour: |
Milky White Translucent |
Melt Point: |
90-120℃ |
Conventional Width: |
500mm,1000mm,1280mm,1480mm |
Conventional Length: |
100 Yards |
Dry Cleaning Resistance Double Sided PES Hot Melt Glue Film For PVC
PES Hot Melt Glue Film Description
This product is a thermoplastic film hot melt adhesive, entrusted to the release of paper, can be repeatedly heated plasticized bonding.This kind of hot melt adhesive has excellent adhesion to textile products, PVC, PC.This product is resistant to dry cleaning and 40℃ washing.
PES Hot Melt Glue FilmTechnical Parameters:
|
Colour |
Milky white translucent |
Release Protection |
Glassine Release Paper |
|
Proportion |
1.15±0.02g/cm³ |
Conventional Thickness |
0.05mm,0.08mm,0.10mm,0.12mm,0.15mm,0.18mm |
|
Melting Range |
90-120℃ (Tunsing DSC 214) |
Width |
10mm-1480mm |
|
Liquidity Index |
32±15g/10min(ASTM D1238-04) |
Conventional Width |
500mm,1000mm,1280mm,1480mm |
|
Activation Temperature |
116-150℃(Tunsing) |
Conventional Length |
100 yards |
|
Washing Resistant |
40℃ |
Finished Product |
500mm*100yards/roll |
PES Hot Melt Glue Film Technical Parameters:
|
First Lamination |
Second Implanting |
||
|
Mechanical Mold Temperature |
130℃-160℃ |
Mechanical Mold Temperature |
130℃-170℃ |
|
Hot Pressing Time |
5-15 seconds |
Hot Pressing Time |
8-25 seconds |
|
Pressure |
0.3-0.6mpa |
Pressure |
0.3-0.6mpa |
Storage conditions
1.The temperature is 20-30"C, the humidity is 45- 55%, there is no ultraviolet light, and it is protected fromlight (light protection includes light and natural light) to avoid long-term contact with the air.
2. If the material is stored in the whole roll, the stacking strength should not be too large, and the stacking height should be moderate.
3. If you don't need to cut pieces, you can keep the original packaging. If cutting pieces cannot be avoided, the excess materials should be sold out within 1 day without good packaging.
Why choose us
a. high intensity and strong bonding;
b. excellent washing& dry cleaning performance;
c. uneasy to change shape;
d. good breath ability;
e. eco-friendly.
PES Hot Melt Glue Film Application
