Home > products > Hot Melt Adhesive Film > 12 Micron Transparent Polyester Film PES Aluminum Metallized Polyester Film

12 Micron Transparent Polyester Film PES Aluminum Metallized Polyester Film

Product Details

Place of Origin: China

Brand Name: TUNSING

Certification: Oeko-tex,RoHS

Model Number: DS615B

Payment & Shipping Terms

Minimum Order Quantity: 100yard

Price: negotiable

Packaging Details: 620mm*100yard/roll

Delivery Time: 3-7 days

Payment Terms: Paypal,Credit card,Alibaba Trade Assurance

Supply Ability: 50000000 roll per month

Get Best Price
Highlight:

12 Micron Transparent Polyester Film

,

Aluminum Metallized Transparent Polyester Film

,

PES Aluminum Metallized Polyester Film

Product Name:
12 Micron Transparent Polyester Film Aluminum Metallized Polyester Film
Material:
PES/Polyester
Length:
100 Yard
Width:
620mm,1000mm
Thickness:
0.05mm 0.08mm 0.1mm 0.12mm
Item Number:
DS615B
Package:
1-2 Rolls Per Ctn
Key Word:
Aluminum Metallized Polyester Film
Product Name:
12 Micron Transparent Polyester Film Aluminum Metallized Polyester Film
Material:
PES/Polyester
Length:
100 Yard
Width:
620mm,1000mm
Thickness:
0.05mm 0.08mm 0.1mm 0.12mm
Item Number:
DS615B
Package:
1-2 Rolls Per Ctn
Key Word:
Aluminum Metallized Polyester Film
12 Micron Transparent Polyester Film PES Aluminum Metallized Polyester Film

12 Micron Transparent Polyester Film Aluminum Metallized Polyester Film

Model:DS615B
Material: PES/Polyester

Quick detail of Aluminum metallized polyester film:
Aluminum metallized polyester film is a thermoplastic film modified hot melt adhesive, entrusted to release paper, can be repeatedly heated plasticizing bonding. Aliuminum metallized polyester film has excellent adhesion to textiles, metals (copper, aluminum, iron, stainless steel), plastics (PC, ABS, glass fiber, etc.), wood and paper.

Application of Aluminum metallized polyester film:
Aluminum metallized polyester film DS615B is used in 3C electronics, 5G, automobile, precision instrument, medical, luggage, sporting goods. Insoluble in ethanol.


The advantages by using aluminum metallized polyester film as follows:

1. Clean;

2. Eco-friendly;

3. High efficiency. The fast bonding speed could make the process done in several seconds.

4. Safety. This product is non-solvent and it could not make any hidden trouble in production;

5. Hot melt adhesive film has good fastness performance than other glue which could be widely used to laminate many materials;

6. Automatic production can be realized.


Product Paramenters of Aluminum metallized polyester film::

Colour

Amber

Proportion

1.05±0.02g/cm³

Melting Range

80-105℃(Tunsing DSC 214)

Melt Flow Index

40±7g/10mins(ASTM D1238-04)

Activation Temperature

115-140℃ (Tunsing)

Release Protection

Glassine Release Paper

Conventional Thickness

0.05mm,0.08mm,0.10mm,0.12mm,0.15mm

Conventional Width

620mm

Conventional Length

100 yard

Finished Product

620mm*100yard/roll



First Lamination:

Mechanical Mold Temperature

150℃-180℃

Hot Pressing Time

8-15 seconds

Pressure

0.4-0.6mpa

Second Implanting:

Mechanical Mold Temperature

150℃-190℃

Hot Pressing Time

15-25 seconds

Pressure

0.4-0.6mpa


Note:
1. Bonding temperature, pressure and time are related to the bonding strength of the film to the material.The bonding temperature must be close to the set temperature of the machine,the pressure must be uniform,and the die and press roller must be flat.
2.The bonding conditions used will be different between different machines and materials.The conditions indicated here are only basic.The optimal bonding conditions should be built by manufacturing to establish the corresponding construction conditions for the particular application.

Packing & Delivery of Aluminum metallized polyester film:
Packing Details:100y/roll , 1-2 rolls/ctn
It depends on the width of hot melt adhesive film.

Delivery Time:Shipped in 3-5 days after payment for sample
Shipped in 3-10 days for mass product

Customer Feedback of Aluminum metallized polyester film::
12 Micron Transparent Polyester Film PES Aluminum Metallized Polyester Film 0


Why Choose Us:

1. We are environmentally friendly adhesive enterprises to ensure the environmental performance of raw materials

2. Own factory, efficient technical equipment, a number of production lines

3. Professional R & D team, set production, research and development, sales as one of the new enterprises

4. Service thoughtful, short delivery cycle



FOQ:

1. who are we?

We are based in Guangdong, China, start from 2007,sell to Domestic Market(50.00%),South

America(12.00%),South Asia(12.00%),North America(6.00%),Southeast Asia(5.00%),Africa

(5.00%),Western Europe(2.00%),Southern Europe(2.00%),Eastern Europe(00.00%),Oceania

(00.00%),Mid East(00.00%),Eastern Asia(00.00%),Central America(00.00%),Northern Europe

(00.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?

Always a pre-production sample before mass production;

Always final Inspection before shipment;

3. what can you buy from us?

Hot Melt Adhesive Film,Hot Melt Adhesive Powder,Hot Melt Adhesive Web Film,Hot Melt

Adhesive Granule,Heat Seam Sealing Tape.

4. why should you buy from us not from other suppliers?

1. ISO9001,ROHS,REACH & Oeko-Tex Standard 100 certification;

2. More than fourteen years experience;

3. Strict quality control;

4. ERP system;
