Product Details
Place of Origin: China
Brand Name: TUNSING
Certification: ISO 9001 SGS Oeke-TEX
Model Number: DS001TS
Payment & Shipping Terms
Minimum Order Quantity: 100yards or 100 meters
Price: Negotation
Packaging Details: 1PC/PE FILM, 100yard/roll, 2~4roll/CTN, or it's up on the customer's option
Delivery Time: 3-5 work days after received the payment
Payment Terms: L/C, T/T, Western Union, Western Union
Supply Ability: 40000 Square meters per day
NAME: |
PES Hot Melt Adhesive Film |
Melting Range: |
80-105℃ (Tunsing DSC 214) |
Melt Flow Index: |
32±15g/10min（ASTM D1238-04） |
Thickness Range: |
0.025mm-0.30mm |
Width Range: |
5mm-1580mm |
Activation Temperature: |
116-150℃ (Tunsing) |
Proportion: |
1.15±0.02g/cm³ |
Operating Temperature: |
130-170℃ |
NAME: |
PES Hot Melt Adhesive Film |
Melting Range: |
80-105℃ (Tunsing DSC 214) |
Melt Flow Index: |
32±15g/10min（ASTM D1238-04） |
Thickness Range: |
0.025mm-0.30mm |
Width Range: |
5mm-1580mm |
Activation Temperature: |
116-150℃ (Tunsing) |
Proportion: |
1.15±0.02g/cm³ |
Operating Temperature: |
130-170℃ |
Best Dry Cleaning Adhesive Film Hot Film High Quality Hot Melt Adhesive Film for PVC
Hot Melt Adhesive Film
hot melt adhesive film that specifically mentions its compatibility and strong adhesion to textile products, PVC, and PC materials. This ensures that the adhesive will effectively bond to these surfaces without compromising the integrity of the bond.The hot melt adhesive film can be repeatedly heated and plasticized for bonding purposes. This allows for flexibility during the application process and ensures a strong and durable bond.The hot melt adhesive film is explicitly mentioned as being resistant to dry cleaning and washing at 40°C. This indicates that the hot melt adhesive film will maintain its bond strength and integrity even when exposed to these cleaning processes.
The physical characteristics of Hot Melt Adhesive Film
Physical Characteristics
| Colour | Milky white translucent |
| Release Layer | Glassine Silicone Release Paper |
| Thickness Range | 0.025mm-0.30mm |
| Width Range | 5mm-1580mm |
| Proportion | 1.15±0.02g/cm³ |
| Melt Flow Index | 32±15g/10min(ASTM D1238-04) |
| Melting Range | 80-105℃ (Tunsing DSC 214) |
| TG Temperature | 0±5℃ (GB/T19466.2-2004) |
| Activation Temperature | 116-150℃ (Tunsing) |
Recommended Bonding Conditions
| First Lamination | Second Implanting | ||
| Mechanical Mold Temperature | 130℃-160℃ | Mechanical Mold Temperature | 130℃-170℃ |
| Hot Pressing Time | 5-15 seconds | Hot Pressing Time | 8-25 seconds |
| Pressure | 0.3-0.6mpa | Pressure | 0.3-0.6mpa |
The Characteristics of Hot Melt Adhesive Film
Polyester (PES) hot melt adhesive film is a type of thermoplastic film that has specific characteristics. Here are some features of PES hot melt adhesive film:
1.Excellent Adhesion: PES hot melt adhesive film exhibits strong adhesion to various substrates, including fabrics, plastics, and metals. PES hot melt adhesive film forms a reliable and durable bond when activated by heat.
2.Heat Activated: PES hot melt adhesive film is designed to be activated by heat. When subjected to elevated temperatures, PES hot melt adhesive film softens and becomes tacky, allowing it to bond with the desired surfaces.
3.Thermoplastic: PES hot melt adhesive film is a thermoplastic material, which means it can be repeatedly heated and cooled without undergoing significant changes in its properties. This feature enables easy reactivation and repositioning during the bonding process.
The Application of PES Hot Melt Adhesive Film
1.Labeling and Decal Industry: Hot melt adhesive film is employed for label and decal applications, providing fast and permanent bonding on various surfaces such as glass, plastic, and metal.
3.PVC Profile Wrapping: PES hot melt adhesive film is applied to wrap and cover PVC profiles, such as window frames, door frames, and furniture edges. It creates a protective layer that enhances the aesthetics, durability, and weather resistance of the PVC profiles.
PES Hot Melt Adhesive Film's Customer Feedback
PES Hot Melt Adhesive Film
Packing & Shipping :
Packing: 100 yard in roll, 1-2 rolls in case
Shipping: 5-7days by Express (DHL, FedEx, USP and so on)
